Specifications are subject to change without notice
Frequency Response 69–22,000 Hz ±3dB
Recommended Amplifier Power 20‒500 watts per channel
Horizontal Dispersion 30°
Sensitivity 90 dB/2.83 volts/meter
Impedance 4 Ohms . Compatible with 4, 6, or 8 Ohm rated amplifiers.
Crossover Frequency 450, 2700 Hz
High Frequency Transducer One 1" x 1.4" (2.6cm x 3.6cm) Folded Motion Transducer with 5.25" x 1.75" (13.3cm x 4.4cm) diaphragm.
Mid Frequency Transducer Patented CLS™ XStat™ electrostatic transducer
» Panel Dimensions: 7.5" × 18" (19.1 × 45.7cm)
» Radiating Area: 135 in2 (873 cm2)
Low Frequency Transducer Two 6.5" (16.5 cm) cast basket, aluminum cone with extended throw driver assembly, non-resonant asymmetrical chamber format
Components Custom-wound toroidal audio transformer, air core coils, polypropylene capacitors
Inputs Custom 5-way binding posts
Weight 39 lbs. (17.7 kg)
Dimensions (mounting bracket/stand beneath speaker) 12" × 34.6" × 10.3"
(30.4cm × 87.9cm × 26.1cm)
Dimensions (without mounting bracket/stand) 9" × 34.6" × 10.3"
(22.7cm × 87.9cm × 26.1cm)
