The Installer Series™ by MartinLogan is a line of affordable high-performance products, featuring custom installation solutions for in-wall, in-ceiling, and outdoor applications. Manufactured to the highest standards of quality, these products are available through authorized specialty custom installation specialists and carry the full MartinLogan warranty.
Specifications are subject to change without notice
Frequency Response 60–20,000 Hz ±2dB
Recommended Amplifier Power 20—120 watts per channel
Sensitivity 90 dB/2.83 volts/meter
Impedance 8 Ohms. Compatible with 4, 6 or 8 ohm rated amplifiers. Compatible with 4, 6, or 8 Ohm rated amplifiers.
Crossover Frequency 2500 Hz
High Frequency Transducer 1" (2.5cm) titanium dome
Low Frequency Transducer 8" (21cm) mineral-filled polypropylene cone
Inputs Spring clip accommodates wire up to 12AWG
Weight 4.4 lbs. (2 kg)
Cut-Out Dimensions 9.375" dia.
(23.8 cm dia.)
Projection From Wall Surface 0.2" (0.5cm)
Depth Behind Wall Surface 3.8" (9.5 cm)
