Technical Specifications:

Power output @ 1% THD >110 Watts into 8 Ohms, both channels driven

Power output @ 1% THD >170 Watts into 4 Ohms, both channels driven

Continuous output current >8.5A (sine wave)

Peak output current, burst into 0.5 Ohms +/-26 Amps, current burst into 0.5 Ohms

THD and Noise, 2/3 rated power 8 Ohms <0.002% 20 Hz to 20 kHz

Signal to Noise Ratio 102dBA Line input

Frequency Response <10Hz to >100 kHz +/-2dB

Gain at 1 kHz Un-balanced 33.3dB (x 48)

Gain at 1 kHz Balanced 27.0dB (x 22.5)

Input sensitivity, Line level 810mV

Maximum input voltage, RCA and Balanced (XLR) 5.4V and 10.8V r.m.s.

Crosstalk -80dB at 1 kHz

DC offset < +/-10mV

Pre-Amp Inputs 5 x RCA un-balanced, including optional

Plug-in Phono options Input 1 changes to Phono with Sequel Phono fitted.

Gain: 40, 48 or 54dB

Power amp inputs Inputs 3 & 4 can be assigned as

 Power Amp direct inputs

Tuner option AMBIT Tuner module (optional extra)

DAC option RUBY DAC module (optional extra)

IR BUS For adding an external IR sensor or linking to an

 other product.

Loudspeaker Outputs A+B x2 pairs of high-grade 4mm binding posts

Headphone Output x1 x 6.3mm jack socket with dedicated low imped

ance headphone amp (<50 Ohms)

Output impedance <0.05 Ohms 20Hz to 20 KHz

Mains voltage 230/115V 50/60Hz, switchable

Front panel finish options Silver or Black

Power Consumption: Idle, Max, Standby <20 Watts, 600 Watt, No standby

Weight net 9kgs (20 lbs)

Size W/H/D inc. feet and knobs 430 x 60 x 280mm (17 x 2.3 x 11”)
